Howo Arm Roll Container Truck

WhatsApp：+86-18727988889

WhatsApp：+86-19171788596

Howo Arm Roll Container Truck
General	Chassis Brand	Sinotruk HOWO
	Overall Dimension(L×W×H)	Approx 7000×2500×3200mm
	GVW / Kerb Weight	16000kg / approx 7800kg
	Loading Capacity	8-10m³ / 8-10 tons
	Drive Orientation	Left-hand Drive (LHD)
Cab	Cab Type	High-roof Sleeper Cab (Row-and-a-half)
	Cab Capacity	3 seats (1 driver + 2 passengers) with rear sleeper berth
	Air Conditioner	Standard equipped
	Power Windows	Standard equipped
	Central Lock	Standard equipped
Engine	Fuel Type	Diesel
	Engine Brand	Weichai / Sinotruk original matching engine
	Rated Power	290-340HP/213-250kW
	Displacement	9.7-10L
	Emission Standard	Euro2/Euro3/Euro5/Euro6 optional
Chassis Parameter	Drive Type	4×2
	Transmission	Fast 10-speed manual gearbox with PTO interface
	Wheelbase/No.of axle	4500mm / 2 axles
	Tyre Specification	12R22.5 heavy-duty radial tires
	Tyre Number	6pcs + 1 spare tyre
	Max Speed	90km/h
	Paint	Standard: customized body color (blue/white etc.) + superstructure color
Superstructure	Loading Capacity	8-10m³ / 8-10 tons (customizable)
	Swing Arm System	Domestic famous brand hydraulic swing arm mechanism, single arm design
	Hydraulic System	Domestic brand hydraulic pump & valves, working pressure 16-20MPa
	Control Mode	In-cab manual lever control with safety interlocks; optional wireless remote control
	Swing Arm Performance	Max lifting weight ≥10 tons, max lifting height ≥4m, full loading/unloading cycle time ≤30s
	Standard Accessories	1 standard 8-10m³ garbage bin, anti-slip footstep, safety railing, hydraulic oil tank with filter, overflow protection device
	Anti-corrosion	Epoxy primer + weather-resistant finish paint, anti-rust treatment for all metal parts

View Less

Introduction

Dispersed urban domestic waste, factory industrial residues and construction debris disposal bring huge pressure to global municipal sanitation work. Traditional integrated garbage trucks need to stop and wait for waste loading, causing low sanitation operation efficiency, while ordinary sealed garbage vehicles cannot classify and transfer bulk waste, easily triggering sewage leakage and secondary pollution. Targeting high-efficiency, low-pollution sanitation transportation demands, we supply export-special HOWO Arm Roll Container Truck, also widely known as skip loader or roll-off truck. It is a professional sanitation vehicle equipped with rear hydraulic hook arm mechanism, adopting separated truck-chassis-and-container design to realize automatic loading, unloading and bin detachment. Featuring full hydraulic drive, diverse bin customization and stable operating performance, this HOWO sanitation truck fits municipal cleaning, factory waste clearance and construction residue transportation, fully complying with international environmental protection and vehicle export standards.

1. Product Overview

2. Working Principle

3. Daily Application Scenarios

4. Comparison with Traditional Sanitation Trucks

5. Buying Guide

6. Operation and Maintenance Tips

7. Frequently Asked Questions

Conclusion

1. Product Overview

HOWO Arm Roll Container Truck is an export-oriented dedicated hydraulic sanitation vehicle customized for cross-border municipal environmental protection projects. Different from one-piece sealed garbage trucks, it adopts a fully separated structure of heavy-duty HOWO chassis and independent waste skip bin, which is the most core differentiated design of roll-off sanitation trucks. Breaking the limitation that one truck can only match one fixed carriage, this arm roll truck supports one chassis to cooperate with multiple detachable waste containers, realizing cyclic waste collection and greatly improving daily sanitation working efficiency.

The vehicle is equipped with high-strength rear hydraulic hook arm assembly as the core working component. Driven by high-pressure wear-resistant hydraulic cylinders, the whole loading and unloading cycle including grabbing, lifting, positioning and locking waste bins only takes about 60 seconds. All operation buttons are integrated inside the driving cab, requiring no external manual auxiliary work, which lowers on-site labor cost and avoids sanitation workers’ exposure to polluted waste. The matched hydraulic auxiliary support legs are installed on both rear sides of the chassis, which will automatically extend synchronously during bin lifting to balance vehicle gravity and prevent lateral tilting accidents.

Supporting customized detachable waste containers have diversified configurable functions to adapt to complex waste disposal demands. Standard bins adopt anti-corrosion carbon steel spraying technology; optional configurations include fully sealed anti-leakage lids, hydraulic self-dumping structure and thickened anti-wear lining. Apart from daily municipal domestic waste, the customized bins can load construction debris, industrial scrap and bulk particulate materials, realizing multi-scenario vehicle utilization. All hydraulic components adopt export-grade dustproof and leak-proof accessories, with complete export certification, suitable for long-term high-frequency sanitation operation overseas.

The whole vehicle features compact mechanical layout, simplified hydraulic pipeline routing and reinforced load-bearing beam structure. It effectively reduces mechanical failure rate in high-frequency continuous operation, cuts daily maintenance and spare parts replacement cost, and becomes a cost-effective core vehicle for overseas sanitation departments, environmental protection companies and construction contractors.

Core Product Advantages

Cyclic Bin Matching Design：One truck cooperates with multiple independent waste containers, executing continuous waste collection workflow to boost sanitation efficiency
Full Hydraulic Automatic Operation：Cab integrated control, 60s fast loading & unloading cycle, simple operation without manual auxiliary labor
Anti-tilt Safety Structure：Hydraulic auxiliary support legs for gravity balance, stable lifting posture to eliminate vehicle rollover risks
Leak-proof Environmental Protection：Sealed customized bins isolate waste sewage, prevent ground pollution and odor diffusion
Multi-functional Bin Customization：Optional anti-corrosion coating, self-dumping structure and sealed cover, adaptable for household, industrial and construction waste
Low Operation Cost：Streamlined mechanical structure, low breakdown rate, economical spare parts and daily maintenance
Wide Environmental Adaptability：Applicable for residential communities, urban roads, industrial parks, towns and sanitation transfer stations

2. Working Principle

The automatic waste transportation workflow of HOWO Arm Roll Container Truck relies on HOWO chassis power output, rear hydraulic hook arm linkage system, synchronous telescopic support leg mechanism, bin locking device and customized sealed container auxiliary structure, realizing automatic bin grabbing, loading, transportation, unloading and separation with closed-loop hydraulic control.

After driving to the waste collection site, the operator aligns the truck rear end with the placed empty waste bin, switches on the hydraulic power take-off inside the cab and activates arm roll working mode. The hydraulic system drives bilateral auxiliary support legs to extend vertically and land stably, calibrating chassis horizontal posture to offset gravity deviation caused by heavy bin loading.

Subsequently, the hydraulic hook arm stretches out and locks the reserved hanging point of the waste bin mechanically. After finishing safety locking confirmation, the hydraulic cylinder pushes the hook arm to lift and flip the waste bin backward steadily, placing the whole bin on the chassis bearing beam and activating the automatic locking buckle to fix the bin firmly to prevent sliding during road transportation. The whole grabbing and loading process is finished within 60 seconds.

After transporting waste to disposal stations or transfer stations, the operator releases the bin locking mechanism via cab control. The hydraulic hook arm reverses the lifting action to put down the full-load waste bin and detach the hook structure. The truck can drive away immediately to collect empty bins at other sites, realizing the efficient "truck moves, bins stay" cyclic operation mode. For sealed and self-dumping bins, the auxiliary hydraulic pipeline can trigger bin opening and dumping actions to finish automatic waste discharging.

3. Daily Application Scenarios

Benefiting from detachable bin design, fast hydraulic operation and pollution-proof configuration, the export HOWO arm roll container truck covers municipal sanitation, industrial environmental protection and construction residue transportation scenarios, widely purchased by overseas municipal administration departments, environmental protection enterprises, factory asset management teams and engineering contractors:

Urban Municipal Sanitation: Daily domestic waste collection, street garbage cleaning, public park and scenic area waste disposal, regular urban sanitation operation
Residential Community Cleaning: Decentralized household waste recycling, old community renovation garbage clearance, regular domestic garbage transfer of residential quarters
Industrial Park Waste Transport: Factory production scraps, packaging waste, workshop bulk residue collection and short-distance transportation
Construction & Renovation Project: Building rubble, decoration debris, concrete residue and construction bulk material shuttle transportation
Town & Transfer Station Operation: Inter-shuttle transportation between garbage transfer stations and disposal sites, scattered rural domestic waste centralized collection

Different from traditional integrated garbage trucks that must wait for on-site loading, this arm roll truck separates transportation and waste loading work. Sanitation staff can pre-place empty bins at scattered waste points, and the truck shuttles back and forth for replacement and transportation, greatly cutting idle waiting time and improving overall sanitation operating efficiency.





4. Comparison with Traditional Models

Compared with integrated sealed garbage trucks: Conventional one-piece garbage trucks integrate carriage and chassis, the whole vehicle must stop and wait for waste filling, resulting in low turnover efficiency. Once the carriage is damaged, the whole vehicle cannot work. HOWO arm roll truck separates bin and chassis, realizing independent replacement and cyclic operation to maximize working efficiency.

Compared with manual hanging bin sanitation trucks: Basic hanging bin trucks require workers to hook and unload bins manually, with high labor intensity and sanitation exposure risks. This hydraulic arm roll truck realizes full-cab automatic operation, reducing manpower cost and improving working safety.

Compared with ordinary non-sealed roll-off trucks: Early arm roll trucks adopt open bins, causing sewage dripping, odor leakage and road secondary pollution during driving. This export model supports fully sealed customized bins to meet international environmental protection emission requirements.

Compared with low-load modified skip loaders: Refitted sanitation vehicles lack synchronous support leg structure, easy to tilt and roll over during heavy bin lifting. Genuine HOWO chassis matches original hydraulic balance system and auxiliary legs, with higher operating stability and export qualification validity.

Howo Arm Roll Container Truck
General	Chassis Brand	Sinotruk HOWO
	Overall Dimension(L×W×H)	Approx 7000×2500×3200mm
	GVW / Kerb Weight	16000kg / approx 7800kg
	Loading Capacity	8-10m³ / 8-10 tons
	Drive Orientation	Left-hand Drive (LHD)
Cab	Cab Type	High-roof Sleeper Cab (Row-and-a-half)
	Cab Capacity	3 seats (1 driver + 2 passengers) with rear sleeper berth
	Air Conditioner	Standard equipped
	Power Windows	Standard equipped
	Central Lock	Standard equipped
Engine	Fuel Type	Diesel
	Engine Brand	Weichai / Sinotruk original matching engine
	Rated Power	290-340HP/213-250kW
	Displacement	9.7-10L
	Emission Standard	Euro2/Euro3/Euro5/Euro6 optional
Chassis Parameter	Drive Type	4×2
	Transmission	Fast 10-speed manual gearbox with PTO interface
	Wheelbase/No.of axle	4500mm / 2 axles
	Tyre Specification	12R22.5 heavy-duty radial tires
	Tyre Number	6pcs + 1 spare tyre
	Max Speed	90km/h
	Paint	Standard: customized body color (blue/white etc.) + superstructure color
Superstructure	Loading Capacity	8-10m³ / 8-10 tons (customizable)
	Swing Arm System	Domestic famous brand hydraulic swing arm mechanism, single arm design
	Hydraulic System	Domestic brand hydraulic pump & valves, working pressure 16-20MPa
	Control Mode	In-cab manual lever control with safety interlocks; optional wireless remote control
	Swing Arm Performance	Max lifting weight ≥10 tons, max lifting height ≥4m, full loading/unloading cycle time ≤30s
	Standard Accessories	1 standard 8-10m³ garbage bin, anti-slip footstep, safety railing, hydraulic oil tank with filter, overflow protection device
	Anti-corrosion	Epoxy primer + weather-resistant finish paint, anti-rust treatment for all metal parts

5. Buying Guide

For overseas sanitation departments, environmental protection companies and construction teams purchasing roll-off garbage trucks, prioritize chassis reliability, hydraulic safety performance and bin expandable configurations:

Adopt Genuine HOWO Heavy-Duty Chassis：Select original export-standard HOWO chassis with mature power assembly, stable bearing capacity and global spare parts supply channels.

Verify Full Hydraulic Arm Roll System：Confirm integrated cab control, 60s fast loading cycle and synchronous anti-tilt auxiliary support legs to guarantee operation safety.

Match Customized Waste Containers：Choose sealed bins for municipal domestic waste; select thickened anti-wear bins for construction debris; equip self-dumping structure for large-volume waste disposal.

Check Environmental Protection Configuration：Prioritize anti-leakage sealing and anti-corrosion coating to avoid cross-region environmental inspection risks.

Complete Export Certification：Verify full sets of vehicle qualification and environmental protection documents to ensure barrier-free overseas registration and customs clearance.

6. Operation and Maintenance Tips

This HOWO Arm Roll Container Truck adopts industrial-grade hydraulic arm roll assembly and reinforced sanitation chassis, with strong dust pollution adaptability and long service life. Standardized operation and maintenance can reduce hydraulic failure rate, prolong service life and retain long-term export legal validity:

Daily Operation Specifications

Check hydraulic oil level, hook arm lubrication status and support leg flexibility before daily startup; prohibit operation with insufficient hydraulic pressure
Extend bilateral auxiliary support legs completely before lifting waste bins; forbid bin loading on hollow, sloped and soft ground to prevent tipping
Align hook arm and bin hanging points accurately, confirm mechanical locking buckle is fastened before transportation to avoid bin falling during driving
Clean bin sealing grooves and hook arm sundries after each operation to prevent hard debris from scratching sealing parts and causing sewage leakage
Control driving speed below 60km/h with full-load waste bins, avoid sharp turning and emergency braking to guarantee transportation stability

Regular Maintenance Advice

Replace dedicated anti-corrosion hydraulic oil every 12 months, clean hydraulic oil filter monthly to block dust and sewage impurities from blocking pipelines
Add anti-rust lubricant to hook arm rotating joints and locking parts biweekly to prevent jamming caused by sewage corrosion
Inspect support leg hydraulic sealing rings quarterly, replace aging accessories to prevent oil leakage and unbalanced lifting
Clean waste bins and conduct anti-corrosion spraying every six months, extend service life of customized sanitation containers
Maintain HOWO chassis braking and power system regularly to ensure long-distance stable shuttle transportation

Scientific daily maintenance can cut hydraulic system failure risks, reduce overseas after-sales cost, and keep vehicle sanitation emission and export certification valid permanently.

7. Frequently Asked Questions

Q1: What is another name of HOWO Arm Roll Container Truck?

A1: It is also widely known as a skip loader or roll-off truck, a special hydraulic sanitation vehicle for waste collection and transportation.

Q2: What is the biggest feature of this roll-off garbage truck?

A2: The truck chassis and waste bin are completely independent. One single truck can serve multiple detachable waste containers, realizing continuous high-efficiency waste collection workflow.

Q3: How long does the whole bin loading cycle take?

A3: Powered by full hydraulic cylinders, the whole working cycle including grabbing, lifting, loading and locking the waste bin takes about 60 seconds, operated totally inside the cab.

Q4: What kinds of waste can this sanitation truck transport?

A4: It can handle municipal solid waste, construction debris, industrial scrap and other bulk materials. The containers support customized sealed lids, anti-corrosion coatings and self-dumping functions for diverse demands.

Q5: What safety designs are equipped during lifting operation?

A5: It is fitted with hydraulic auxiliary support legs to stabilize vehicle posture and avoid tilting; matched with mechanical bin locking buckles to prevent bin falling during transportation.

Conclusion

HOWO Arm Roll Container Truck is an export-special hydraulic sanitation vehicle developed aiming at low-efficiency and pollution defects of traditional garbage trucks. Built on mature and reliable HOWO heavy-duty chassis, it adopts separated chassis and detachable bin core design, breaking the working limitation of integrated sanitation vehicles. Supported by high-response full hydraulic hook arm system, it realizes 60-second fast automatic loading and unloading, cooperated with synchronous anti-tilt support legs to guarantee full-operation safety.

With customizable sealed and anti-corrosion waste containers, this skip loader solves sewage leakage and secondary environmental pollution problems, adapting to municipal cleaning, industrial residue disposal and construction waste transportation multi-scenarios. Featuring simple mechanical structure, low failure rate and economical maintenance cost, it effectively cuts daily operation labor and equipment expenditure for overseas sanitation teams.

Equipped with complete international environmental protection and export customs clearance certification, this HOWO roll-off truck removes overseas vehicle registration, environmental inspection and spare parts supply obstacles. Balancing operating efficiency, transportation safety and environmental protection performance, it is reliable long-term sanitation engineering equipment for global municipal departments, environmental protection enterprises and construction contractors, providing efficient and eco-friendly one-stop waste collection and transportation solutions.


Howo Arm Roll Container Truck
General	Chassis Brand	Sinotruk HOWO
	Overall Dimension(L×W×H)	Approx 7000×2500×3200mm
	GVW / Kerb Weight	16000kg / approx 7800kg
	Loading Capacity	8-10m³ / 8-10 tons
	Drive Orientation	Left-hand Drive (LHD)
Cab	Cab Type	High-roof Sleeper Cab (Row-and-a-half)
	Cab Capacity	3 seats (1 driver + 2 passengers) with rear sleeper berth
	Air Conditioner	Standard equipped
	Power Windows	Standard equipped
	Central Lock	Standard equipped
Engine	Fuel Type	Diesel
	Engine Brand	Weichai / Sinotruk original matching engine
	Rated Power	290-340HP/213-250kW
	Displacement	9.7-10L
	Emission Standard	Euro2/Euro3/Euro5/Euro6 optional
Chassis Parameter	Drive Type	4×2
	Transmission	Fast 10-speed manual gearbox with PTO interface
	Wheelbase/No.of axle	4500mm / 2 axles
	Tyre Specification	12R22.5 heavy-duty radial tires
	Tyre Number	6pcs + 1 spare tyre
	Max Speed	90km/h
	Paint	Standard: customized body color (blue/white etc.) + superstructure color
Superstructure	Loading Capacity	8-10m³ / 8-10 tons (customizable)
	Swing Arm System	Domestic famous brand hydraulic swing arm mechanism, single arm design
	Hydraulic System	Domestic brand hydraulic pump & valves, working pressure 16-20MPa
	Control Mode	In-cab manual lever control with safety interlocks; optional wireless remote control
	Swing Arm Performance	Max lifting weight ≥10 tons, max lifting height ≥4m, full loading/unloading cycle time ≤30s
	Standard Accessories	1 standard 8-10m³ garbage bin, anti-slip footstep, safety railing, hydraulic oil tank with filter, overflow protection device
	Anti-corrosion	Epoxy primer + weather-resistant finish paint, anti-rust treatment for all metal parts
