Dongfeng Roll-off Skip Loader Garbage Truck

WhatsApp：+86-18727988889

WhatsApp：+86-19171788596

Dongfeng Roll-off skip loader
General	Chassis Brand	Dongfeng Tianjin
	Overall Dimension(L×W×H)	Approx 7500×2500×3200mm
	GVW / Kerb Weight	16000kg / approx 7800kg
	Loading Capacity	8-10m³ / 8-10 tons
	Drive Orientation	Left-hand Drive (LHD)
Cab	Cab Type	Sleeper Cab (Row-and-a-half)
	Cab Capacity	2 seats (1 driver + 1 passenger) with rear sleeper berth
	Air Conditioner	Standard equipped
	Power Windows	Standard equipped
	Central Lock	Standard equipped
Engine	Fuel Type	Diesel
	Engine Brand	Dongfeng Cummins / Yuchai (alternative optional)
	Rated Power	180-210HP/132-154kW
	Displacement	4.5-6.7L
	Emission Standard	Euro2/Euro3/Euro5/Euro6 optional
Chassis Parameter	Drive Type	4×2
	Transmission	Fast 8-speed manual gearbox with PTO interface
	Wheelbase/No.of axle	4700mm / 2 axles
	Tyre Specification	10.00R20 heavy-duty radial tires
	Tyre Number	6pcs + 1 spare tyre
	Max Speed	90km/h
	Paint	Standard: white cab + customized superstructure color
Superstructure	Loading Capacity	8-10m³ / 8-10 tons (customizable)
	Swing Arm System	Domestic famous brand hydraulic swing arm mechanism, single arm design
	Hydraulic System	Domestic brand hydraulic pump & valves, working pressure 16-20MPa
	Control Mode	In-cab manual lever control with safety interlocks; optional wireless remote control
	Swing Arm Performance	Max lifting weight ≥10 tons, max lifting height ≥4m, full loading/unloading cycle time ≤30s
	Standard Accessories	1 standard 8-10m³ garbage bin, anti-slip footstep, safety railing, hydraulic oil tank with filter, overflow protection device
	Anti-corrosion	Epoxy primer + weather-resistant finish paint, anti-rust treatment for all metal parts

View Less

Introduction

Dongfeng Roll-off skip loader (also widely known as a skip loader or roll-off truck) is a specialized sanitation vehicle designed to collect and transport waste using a hydraulically powered hook arm mechanism. Its defining feature is the ability to automatically load, unload, and detach a separate waste container (skip/roll-off bin) from the truck chassis.

Core Characteristics & Key Details

Detachable Container Design

The truck chassis and waste bin are completely independent. A single truck can serve multiple bins, enabling a continuous "truck moves, bins stay" workflow. This drastically improves collection efficiency, especially for scattered waste points or locations with variable waste volumes.

Hydraulic Hook Arm System

The core working component is the rear-mounted hook arm assembly. Powered by hydraulic cylinders, it performs the full cycle of grabbing, lifting, loading/unloading, and securing the waste bin in about 60 seconds. The system is fast, reliable, and operated from the cab.

Multi-Purpose Versatility

The waste containers can be customized (e.g., with sealed lids, self-dumping capability, corrosion-resistant coatings) to handle not only municipal solid waste but also construction debris, industrial scrap, and other bulk materials.

Typical Applications

It is widely used for waste collection in urban streets, residential communities, factories, and towns. It also serves as an efficient short-haul transport tool for construction and renovation waste, particularly ideal for shuttle operations between transfer stations and dispersed collection points.

1. Product Overview

2. Working Principle

3. Daily Application Scenarios

4. Comparison with Traditional Sanitation Trucks

5. Buying Guide

6. Operation and Maintenance Tips

7. Frequently Asked Questions

Conclusion

1. Product Overview

Core Advantages

1. One truck can operate with multiple separate waste containers to raise collection efficiency.

2. Full hydraulic drive ensures quick loading and unloading with simple operation.

3. Auxiliary support legs keep stable lifting to avoid vehicle tilting.

4. Sealed bins prevent sewage leakage and secondary environmental pollution.

5. Compact mechanical structure brings low breakdown rate and economical maintenance.

6. Widely adaptable for residential quarters, factories, towns and municipal sanitation projects.

2. Full hydraulic drive ensures quick loading and unloading with simple operation.

3. Auxiliary support legs keep stable lifting to avoid vehicle tilting.

4. Sealed bins prevent sewage leakage and secondary environmental pollution.

5. Compact mechanical structure brings low breakdown rate and economical maintenance.

6. Widely adaptable for residential quarters, factories, towns and municipal sanitation projects.

2. Working Principle

The whole working principle of Dongfeng Roll-off Skip Loader relies on commercial chassis power output and rear-mounted hydraulic hook arm mechanism. Driven by hydraulic power, the rear hook arm carries out automatic grabbing, lifting, loading and unloading actions for detachable waste skip bins.

The operator controls all hydraulic actions via in-cab lever. Auxiliary support legs extend before lifting to balance vehicle gravity and prevent tipping. The standardized rear hook arm finishes full working cycle within 60 seconds, locking bin hanging points firmly to avoid falling-off risks.

Benefiting from fully separated chassis-bin structure, the roll-off skip loader can leave empty bins on collection sites and transport full waste bins outward, realizing mature "truck moves, bins stay" cyclic collection workflow.

3. Daily Application Scenarios

Municipal Sanitation: Daily waste collection on urban narrow roads, downtown streets and public zones
Residential Community Cleaning: Household waste collection in dense residential quarters and villa communities
Industrial Park Service: Production debris, packaging waste disposal for factories and industrial zones
Public Facilities Sanitation: Waste collection for schools, hospitals and scenic spots

4. Comparison with Traditional Models

Vs Integrated Garbage Trucks: Conventional integrated sanitation trucks adopt fixed carriage structure, requiring long downtime for waste loading. Dongfeng roll-off skip loader matches multiple independent separate bins to realize non-stop cyclic operation.

Vs Ordinary Sanitation Vehicles: Most traditional waste trucks lack independent hook-lift hydraulic structure, unable to separate bins from vehicle body. Dongfeng roll-off skip loader features detachable bin design to cut operational cost.

Vs Manual Waste Collection: Manual cleaning requires massive labor cost and faces hygiene risks. This hydraulic Dongfeng roll-off skip loader supports full-automatic operation, cutting labor input greatly.

Dongfeng Roll-off skip loader
General	Chassis Brand	Dongfeng Tianjin
	Overall Dimension(L×W×H)	Approx 7500×2500×3200mm
	GVW / Kerb Weight	16000kg / approx 7800kg
	Loading Capacity	8-10m³ / 8-10 tons
	Drive Orientation	Left-hand Drive (LHD)
Cab	Cab Type	Sleeper Cab (Row-and-a-half)
	Cab Capacity	2 seats (1 driver + 1 passenger) with rear sleeper berth
	Air Conditioner	Standard equipped
	Power Windows	Standard equipped
	Central Lock	Standard equipped
Engine	Fuel Type	Diesel
	Engine Brand	Dongfeng Cummins / Yuchai (alternative optional)
	Rated Power	180-210HP/132-154kW
	Displacement	4.5-6.7L
	Emission Standard	Euro2/Euro3/Euro5/Euro6 optional
Chassis Parameter	Drive Type	4×2
	Transmission	Fast 8-speed manual gearbox with PTO interface
	Wheelbase/No.of axle	4700mm / 2 axles
	Tyre Specification	10.00R20 heavy-duty radial tires
	Tyre Number	6pcs + 1 spare tyre
	Max Speed	90km/h
	Paint	Standard: white cab + customized superstructure color
Superstructure	Loading Capacity	8-10m³ / 8-10 tons (customizable)
	Swing Arm System	Domestic famous brand hydraulic swing arm mechanism, single arm design
	Hydraulic System	Domestic brand hydraulic pump & valves, working pressure 16-20MPa
	Control Mode	In-cab manual lever control with safety interlocks; optional wireless remote control
	Swing Arm Performance	Max lifting weight ≥10 tons, max lifting height ≥4m, full loading/unloading cycle time ≤30s
	Standard Accessories	1 standard 8-10m³ garbage bin, anti-slip footstep, safety railing, hydraulic oil tank with filter, overflow protection device
	Anti-corrosion	Epoxy primer + weather-resistant finish paint, anti-rust treatment for all metal parts

5. Buying Guide

For global sanitation purchasers, verify core configurations before purchasing qualified Dongfeng roll-off skip loaders:

Heavy-Duty Chassis: Adopt certified heavy-duty commercial chassis to guarantee bearing capacity and road adaptability.

Rear-Mounted Hydraulic Hook Arm: Check original matched rear hydraulic hook assembly, 60-second full working cycle, cab integrated control for stable operation.

Sealed Containers: Choose anti-corrosion sealed skip bins to comply with international environmental protection requirements.

Safety Devices: Equip hydraulic stabilizing legs and anti-drop locking devices to eliminate dumping risks.

Complete Export Certificates: Provide full sets of export documents for overseas customs clearance and vehicle registration.

6. Operation and Maintenance Tips

Standard operation and routine maintenance can protect hydraulic components, extend vehicle lifespan and reduce operation failures:

Daily Operation Specifications

Inspect hydraulic oil pressure and swing arm lubrication before startup; forbid overload dumping
Extend hydraulic stabilizing legs fully before bin lifting to prevent vehicle tipping
Align swing arm hook with bin hanging points accurately to avoid bin falling off
Operate hydraulic system gently, prevent abrupt action to protect hydraulic cylinders
Clean bin sealing grooves after operation to guarantee sealing performance

Regular Maintenance Advice

Replace hydraulic oil every 12 months, clean hydraulic filter regularly
Lubricate swing arm rotation joints biweekly to avoid jamming
Check hydraulic sealing rings monthly to prevent oil leakage
Repaint anti-rust coating on bins and swing arms to resist corrosion
Calibrate hydraulic locking device quarterly to ensure operational safety

7. Frequently Asked Questions

Q1: What are official international names of this sanitation vehicle?

A1: Its universal names include Skip Loader Garbage Truck, Dongfeng Roll-off Skip Loader, Container-Type Waste Collection Vehicle and Hydraulic Swing Arm Waste Truck.

Q2: What is the biggest difference from ordinary garbage trucks?

A2: It adopts rear-mounted hydraulic swing arm structure and detachable skip containers, realizing full-automatic hydraulic operation, with higher efficiency and site adaptability.

Q3: Does it support single-person operation?

A3: Yes. The whole picking, lifting and dumping process can be finished by one driver inside the cab, no extra labor required.

Q4: How to avoid secondary pollution during transportation?

A4: Equipped with fully sealed truck body and skip containers, it blocks sewage leakage, dust and odor diffusion to realize eco-friendly transportation.

Q5: What safety configurations are equipped?

A5: It is fitted with hydraulic stabilizing legs and hydraulic locking devices, plus anti-tipping hydraulic program to guarantee dumping safety.

Conclusion

Dongfeng Roll-off Skip Loader (also named skip loader or roll-off truck) is a professional sanitation vehicle equipped with rear hydraulic hook arm mechanism. With detachable bin design and mature hydraulic system, it supports automatic bin loading, unloading and separation.

Integrated with high efficiency, labor cost saving, flexible accessibility, environmental protection and operational safety, this vehicle solves defects of low efficiency, labor-intensive work and pollution risks of traditional sanitation equipment. It fits municipal, residential, industrial and public sanitation scenarios perfectly.

With standardized hydraulic components and export-compliant configurations, it is reliable, easy-maintenance sanitation equipment for global environmental protection and municipal clients.

Dongfeng Roll-off skip loader
General	Chassis Brand	Dongfeng Tianjin
	Overall Dimension(L×W×H)	Approx 7500×2500×3200mm
	GVW / Kerb Weight	16000kg / approx 7800kg
	Loading Capacity	8-10m³ / 8-10 tons
	Drive Orientation	Left-hand Drive (LHD)
Cab	Cab Type	Sleeper Cab (Row-and-a-half)
	Cab Capacity	2 seats (1 driver + 1 passenger) with rear sleeper berth
	Air Conditioner	Standard equipped
	Power Windows	Standard equipped
	Central Lock	Standard equipped
Engine	Fuel Type	Diesel
	Engine Brand	Dongfeng Cummins / Yuchai (alternative optional)
	Rated Power	180-210HP/132-154kW
	Displacement	4.5-6.7L
	Emission Standard	Euro2/Euro3/Euro5/Euro6 optional
Chassis Parameter	Drive Type	4×2
	Transmission	Fast 8-speed manual gearbox with PTO interface
	Wheelbase/No.of axle	4700mm / 2 axles
	Tyre Specification	10.00R20 heavy-duty radial tires
	Tyre Number	6pcs + 1 spare tyre
	Max Speed	90km/h
	Paint	Standard: white cab + customized superstructure color
Superstructure	Loading Capacity	8-10m³ / 8-10 tons (customizable)
	Swing Arm System	Domestic famous brand hydraulic swing arm mechanism, single arm design
	Hydraulic System	Domestic brand hydraulic pump & valves, working pressure 16-20MPa
	Control Mode	In-cab manual lever control with safety interlocks; optional wireless remote control
	Swing Arm Performance	Max lifting weight ≥10 tons, max lifting height ≥4m, full loading/unloading cycle time ≤30s
	Standard Accessories	1 standard 8-10m³ garbage bin, anti-slip footstep, safety railing, hydraulic oil tank with filter, overflow protection device
	Anti-corrosion	Epoxy primer + weather-resistant finish paint, anti-rust treatment for all metal parts
